TOKYO KEIKI SQP432-38-30-19-86CCC-18 SQP Series Triple Vane Pump
| Brand Name |
TOKYO KEIKI |
| Model Number |
SQP432-38-30-19-86CCC-18 |
| Min.Order Quantity |
1 pcs |
| Price |
Negotiable |
Product Features
TOKYO KEIKI SQP432-38-30-19-86CCC-18 bearing Size Chart (mm/inches) |
|---|
| d | 60 mm |
| D | 95 mm |
| B | 18 mm |
| d1 | 69.4 mm |
| D1 | 88.2 mm |
| rs min | 1.1 mm |
| Radial clearance class | CN |
| Mass | 0.38 kg |
| Dynamic load, C | 31 kN |
| Static load, C0 | 24.2 kN |
| Fatigue limit load, Cu | 1.1 kN |
| f0 | 15.4 |
| Nref | 7,600 rpm |
| Nlim | 11,000 rpm |
| Min operating temperature, Tmin | -40 °C |
| Max operating temperature, Tmax | 120 °C |
| Characteristic cage frequency, FTF | 0.43 Hz |
| Characteristic rolling element frequency, BSF | 7 Hz |
| Characteristic outer ring frequency, BPF0 | 5.59 Hz |
| Characteristic inner ring frequency, BPFI | 7.41 Hz |
| da min | 66.5 mm |
| da max | 69.4 mm |
| Da max | 88.5 mm |
| ra max | 1 mm |
